Description
The Acue Lighting Halo Wash 740 LED Moving Head is a compact LED Beam/Wash fixture that packs a mean punch. It features 7x40W RGBW LEDs which are full pixel controllable in full DMX channel mode.
The Halo Wash 740 also features a wide zoom range from 4.5˚ to 45˚, this allows for very tight beams as well as a nice even wash. In addition to having a motorized zoom option, the Halo Wash 740 also features a rotating front face which creates a “kaleidoscope” effect blasting sharp beams of light to mesmerize your audience. This compact fixture also features 3 phase motors, which allow for very fast and accurate movements.
The Halo Wash 740 is the perfect choice for small to mid-size venues or stages which focus on physically smaller fixtures without sacrificing light output to create their desired lighting designs.
- The Halo Wash 740 is sold as a package only. The package includes four fixtures and a custom flight case
USER MANUAL: Acue Lighting Halo Wash 740 User Manual
| Light Source | 7x40W RGBW LEDs (Pixel Controllable) |
| Operating Modes | DMX, Auto-Program, Sound Active |
| DMX Channels | 23, 35, & 51 Channel modes w/ 3-pin DMX in/out connectors (5 pin optional) |
| Pan | 540˚ |
| Tilt | 205˚ |
| Dimmer | 0-100% Linear dimmer control by DMX |
| Shutter | 2 Shutter Modes. Synchronous Strobe & Random Flash |
| Total Power Draw | 400 Watts |
| Input Voltage | 100-240V AC 50/60hz Power-con power input/output |
| IP Rating | IP 20 (indoor use only) |
