Description

Acue’s Flex Modules and Spheres are Curve-able Magnetic Modules, with a rubberized finish.  These modules are easy to install.  We also offer custom framing design.  All of our flex modules have an IP rating of IP54 making these modules splash-proof.

All Our flex modules and spheres are custom made to order so you will need to contact one of our sales representatives for a quote.

We offer plug and play solutions for all of our custom flex module and sphere options. This includes all the materials needed to put the design together, power supplies, receiving cards, sending cards, as well as all other items needed to operate.

Pixel Pitch (mm): P2.5
LED Configuration: SMD 1010
Pixel Density (pixel/m2): 160,000
Module Size (mm): 240*120*1.6
Module Resolution (dot): 96*48
Scan Mode: 24s
Brightness (cd/m2): 800-1200
Viewing Angle: 120˚
IP Rating: IP54
Brightness Adjustment: 0-255
Control Mode: Synchronous display with PC control via DVI (Novastar Recommended)
Voltage: 5V
Operating Temp: 20˚C to + 60˚C
Operating Humidity: 10~90% RH
Lifespan (h): 50,000 Hours

Pixel Pitch (mm): P3
LED Configuration: SMD 1515
Pixel Density (pixel/m2): 111,111
Module Size (mm): 240*120*1.6
Module Resolution (dot): 80*40
Scan Mode: 20s
Brightness (cd/m2): 800-1200
Viewing Angle: 120˚
IP Rating: IP54
Brightness Adjustment: 0-255
Control Mode: Synchronous display with PC control via DVI (Novastar Recommended)
Voltage: 5V
Operating Temp: 20˚C to + 60˚C
Operating Humidity: 10~90% RH
Lifespan (h): 50,000 Hours

Pixel Pitch (mm): P4
LED Configuration: SMD 2121
Pixel Density (pixel/m2): 62,500
Module Size (mm): 256*128 or 240*240
Module Resolution (dot): 64*32 or 60*60
Scan Mode: 16s or 15s
Brightness (cd/m2): 800-1200
Viewing Angle: 120˚
IP Rating: IP54
Brightness Adjustment: 0-255
Control Mode: Synchronous display with PC control via DVI (Novastar Recommended)
Voltage: 5V
Operating Temp: 20˚C to + 60˚C
Operating Humidity: 10~90% RH
Lifespan (h): 50,000 Hours

Pixel Pitch (mm): P5
LED Configuration: SMD 2121
Pixel Density (pixel/m2): 40,000
Module Size (mm): 320*160*1.6
Module Resolution (dot): 64*32
Scan Mode: 16s
Brightness (cd/m2): 800-1200
Viewing Angle: 120˚
IP Rating: IP54
Brightness Adjustment: 0-255
Control Mode: Synchronous display with PC control via DVI (Novastar Recommended)
Voltage: 5V
Operating Temp: 20˚C to + 60˚C
Operating Humidity: 10~90% RH
Lifespan (h): 50,000 Hours

Pixel Pitch (mm): P6
LED Configuration: SMD 3528
Pixel Density (pixel/m2): 27,777
Module Size (mm): 192*192*1.6
Module Resolution (dot): 32*32
Scan Mode: 8s
Brightness (cd/m2): 800-1200
Viewing Angle: 120˚
IP Rating: IP54
Brightness Adjustment: 0-255
Control Mode: Synchronous display with PC control via DVI (Novastar Recommended)
Voltage: 5V
Operating Temp: 20˚C to + 60˚C
Operating Humidity: 10~90% RH
Lifespan (h): 50,000 Hours

Pixel Pitch (mm): P8
LED Configuration: SMD 3528
Pixel Density (pixel/m2): 15,625
Module Size (mm): 256*128*1.6
Module Resolution (dot): 32*16
Scan Mode: 4s
Brightness (cd/m2): 800-1200
Viewing Angle: 120˚
IP Rating: IP54
Brightness Adjustment: 0-255
Control Mode: Synchronous display with PC control via DVI (Novastar Recommended)
Voltage: 5V
Operating Temp: 20˚C to + 60˚C
Operating Humidity: 10~90% RH
Lifespan (h): 50,000 Hours
