Description

The AVLP400 is and LED Video Processor is designed to input data from common display inputs (HDMI, VGA, DVI, SDI, & USB) and convert the signal to be outputted on LED video wall panels which run Novastar receiving cards.

The ALVP400 runs on a Novastar system making it easy for mapping LED video wall panels. This processor features multiple input and output resolutions which can be customized to fit the user’s needs.

This processor also features a USB port used for connecting the processor to the Novastar Smart LCT and LCT systems running on Windows only based systems.

FEATURES:

    • INCLUDES 1 x Built-in NOVASTAR MCTRL600 Sending Card
    • Maximum Input Resolution: 1920 x 1200 @ 60Hz
    • Custom Input Resolutions Supported: Maximum Width 3840 (3840 x 600 @60Hz) Maximum Height 3840 (548 x 3840 @60Hz)
    • 4x RJ45 Gigabit Ethernet Output Ports: 650,000 Pixels Max Output per Port
    • Supports USB Playback
    • Seamless Switching between all inputs
    • Audio Output Function
    • Signal Detection Function
    • 5-Channel Digital-Analog Video Input (1x SDI, 1x DVI, 1x HDMI, 1x VGA, 1x USB)
    • 10 Recallable Modes
Output Resolutions 4x RJ45 Gigabit Ethernet Output Ports: 650,000 Pixels Max Output per Port
Power Supply Built in 100~240V AC, 50/60Hz
